Description

BESANTEK Multi-Purpose Digital High Voltage Phasing Meter is designed to measure both of AC high voltage and DC high voltage up to 50kV.

UPC Number: 752830840362



Features

  • AC 50kV and DC 50kV measurement with direct reading.
  • 4000-count LCD.
  • Input impedance: 400M.
  • Auto-ranging:
  • – AC: 4.000kV/40.00kV/50.0kV.
  • – DC: 4.000kV/40.00kV/50.0kV.
  • It must be connected with an approved hot stick.
  • Check phases are in-phase or out of phase.
  • Polarity indication: positive/negative.
  • Backlight function.
  • Auto power off.
  • Low battery warning indicator(Multi-level).
  • Protection class: IP66.
  • Accessories: Instruction manual, “Y” contact electrode 2, test hook (contact electrode) 2,insulated rod 2, alkaline batteries, carry case, piercing tip 2 (optional).

Tech. Specification

AC Voltage



Range

4.000kV

40.00kV

50.0kV

Resolution

0.001kV

0.01kV

0.1kV

Accuracy

0~30kV: (4.0%rdg+0.1kV)
30kV~50kV: (5.0%rdg+0.5kV)

DC Voltage

Range

4.000kV

36.00kV

50.0kV

Resolution

0.001kV

0.01kV

0.1kV

Accuracy

0~20kV: (2.0%rdg+0.08kV)
20kV~50kV: (3.0%rdg+0.1kV)

Low Battery Indication

(Multi-level)

Operating Temperature & Humidity

0C to 40C/80% max.

Storage Temperature & Humidity

-10C to 50C/80% max.

Power Source

1.5V (AA) Alkaline battery x 2

Dimensions

Master stick: 490 (L) x 101 (W) x 118 (D) mm

Slave stick: 490 (L) x 35 (W) x 35 (D) mm

Weight

Approx. 1.35kg (battery included)



Ordering Info.

  • BESANTEK BST-HVD27 Multi-Purpose Digital High Voltage Phasing Meter
